Inconel 600 Round Stainless Steel Hollow Bar ASTM B166 800GB S32205

Place of Origin Mainland China
Brand Name TISCO
Certification SGS ISO ROHS
Model Number 304 310 309 410 420 430 etc
Minimum Order Quantity 1ton
Price negotiation
Packaging Details Standard Waterproof Package
Delivery Time 6-10Days after confirming order
Payment Terms L/C, T/T, Western Union
Supply Ability 1000TONS PER MONTH

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Product Name ASTM B166 600 Inconel Bright Bar Standard ASTM/JIS/DIN/GB
Technique Cold Rolled Hot Rolled Certificate ISO
Grade Nickle, Inconel 600 Ultimate Strength 550
High Light

stainless steel hollow bar ASTM B166

,

stainless steel hollow bar 800GB

,

inconel 600 round bar S32205

Leave a Message
Product Description

ASTM B166 Inconel Bar Incoloy 800 Alloy Bar Inconel 600 Alloy Rod Wire Cutting



Inconel 800 Inconel Bar is a nickel-based super alloy that is well suited for applications requiring high strength in temperature ranges from cryogenic up to 1400°F. Inconel 718 also exhibits excellent tensile and impact strength.
Inconel800 alloy is a precipitation hardening nickel-chromium-iron alloy containing niobium and molybdenum. It has high strength, good toughness and corrosion resistance in high and low temperature environments below 650°C. Its state can be solid solution treatment



Product Description



Material Monel/Inconel/Hastelloy/Duplex Steel/PH Steel/Nickel Alloy
Shape Bar,Pipe/tube,sheet/plate,Forging,Ring,Coil,Flange,Ribbon,Square pipe/bar,
Grade Duplex: 2205(UNS S31803/S32205),2507(UNS S32750),UNS S32760(Zeron 100),2304,904L
Hastelloy: Hastelloy B/ -2/B-3/C22/C-4/S/ C276/C-2000/G-35/G-30/X/N/g;etc
Inconel 600/601/602CA/617/625/713/718/738/X-750;ETC
Incoloy: Incoloy 800/800H/800HT/825/925/926;etc
GH: GH2132,GH3030,GH3039,GH3128,GH4180,GH3044,etc
Monel: Monel 400/K500/R405,etc
Nitronic: Nitronic 40/50/60;etc
Nimonic: Nimonic 75/80A/90/A263 ;etc
Specification Wire: 0.01-10mm
Strip: 0.05*5.0-5.0*250mm
Bar: φ4-50mm;Length 2000-5000mm
Pipe: φ6-273mm;δ1-30mm;Length 1000-8000mm
Sheet: δ 0.8-36mm;Width 650-2000mm;Length 800-4500mm
Product
Characteristics
1.According to the preparation process can be divided into deformation superalloys,
casting superalloys and powder metallurgy superalloys.
2.According to the strengthening mode, there are solid solution strengthening type, precipitation
strengthening type, oxide dispersion strengthening type and fiber strengthening type, etc..
Inspection ISO,SGS,BV and so on.
Packaging All our products are packed, stored, transported according to the international regulation.Or as customer's requirement provide special packing.




Dimensions Standard,weight chart and size schedules of Inconel 600 stainless steel Tube

SS Inconel 600 Tube Size(mm) SSInconel 600 Tube Weight per Unit Area(kg/m)
6*1 0.125
6*1.5 0.168
8*1 0.174
8*1.5 0.243
10*1 0.224
10*1.5 0.318
12*1 0.274
12*1.5 0.392
12*2 0.498
14*1 0.324
14*2 0.598
14*3 0.822
16*2 0.697
16*3 0.971
17*3 1.046
18*1 0.423
18*1.5 0.617
18*2 0.797
18*3 1.121
20*1 0.473
20*2 0.897
20*3 1.27
21*3 1.345
22*2 0.996
22*2.5 1.214

Price list

Stainless Steel Inconel 600 Tube ASTM B168/ASME SB-168 Type Inconel 600 Tube FOB Shanghai Per Unit (USD)
2mm Inconel 600 stainless steel Tube $8000.00-$10000.00
ss Inconel 600 mirror Stainless Steel Tube $11000.00-$12000.00
Inconel 600 Stainless Steel Pipe  $15000.00-$20000.00
1'sus Inconel 600 grade Tube $15000.00-$20000.00
Features: nickel-chromium alloy with good oxidation resistance at higher temperatures, with good resistance in carburizing and chloride containing environments.

Inconel 600 is a nickel-chromium alloy designed for use from cryogenic to elevated temperatures in the range of 2000 deg F(1093 deg C). The high nickel content of the alloy enables it to retain considerable resistance under reducing conditions and makes it resistant to corrosion by a number of organic and inorganic compounds. The nickel content gives it excellent resistance to chloride-ion stress-corrosion cracking and also provides excellent resistance to alkaline solutions.

Alloy 600 is non-magnetic, has excellent mechanical properties and a combination of high strength and good workability and is readily weldable. Inconel 600 exhibits cold forming characteristics normally associated with chromium-nickel stainless steels.

Applications: Typical corrosion applications include titanium dioxide production (chloride route), perchlorethylene syntheses, vinyl chloride monomer (VCM), and magnesium chloride. Alloy 600 is used in chemical and food processing, heat treating, phenol condensers, soap manufacture, vegetable and fatty acid vessels and many more.

Chemical Composition

Cr Ni Mn S Fe Si Cu C
14.00-17.00 72.0 min 1.0 max 0.015 max 6.0-10.0 0.50 max 0.50 max 0.15 max


Density and Melting point

Density Melting point
8.47g/cm³ 1370-1425 ℃

 Mechanical Properties

Finish Condition Tensile strength Rm N/mm² Yield strength R P 0. 2N/mm² Elongation (A 5%) Min HB
Solution treatment 550 240 30 ≤195
