32mm 3 Inch Stainless Steel Duct Pipe Gauge SS301 304 Tubing ASTM
Product Details
| Product Name: | Customized Seamless Tubes 316 Gauge 304 Stainless Steel Pipe | Material: | 200 Series/300 Series/400series |
|---|---|---|---|
| Application: | Construction, Decoration, Industry, Machine Building, Exhaust Pipe | Steel Grade: | 300 Series, 400 Series, 200 Series |
| Type: | Welded, Seamless, Liquefied Petroleum Gas, Seamless And Welded, Hot Rolled / Cold Rolled | Standard: | ASTM, JIS, AISI, DIN, EN |
| Thickness: | 0.4-30mm, 1mm-40mm, 1mm-150mm(SCH10-XXS), According To Your Demand, 1.65mm | Processing Service: | Bending Cutting Welding Punching |
| Highlight |
32mm stainless steel duct pipe Gauge,stainless steel duct pipe SS301 304,3 inch stainless steel tubing ASTM |
||
Product Description
Customized Seamless Tubes 316 Gauge 304 Stainless Steel Pipe
Originally 3CR12 was not included in any international specifications. However, a 12 per cent chromium steel developed from 3CR12 has been designated DIN type 1,4003 and ASTM/ASME 41003. The former has been incorporated into two Euronorm Standards viz. EN 10088 and EN 10028, 3CR12 conforms to the requirements of the above specifications and is multi certifiable to 3CR12, 1.4003 and 41003, due to its inclusion in the above specifications. 3CR12 vessels and tanks can be designed in accordance to BS5500, ASME, AD Merkblatter codes and the Euronorm design specification currently in preparation.
Product Description
| Product name | Customized seamless tubes 316 gauge 304 stainless steel pipe price | ||
| Brand | BAOSTEEL, JISCO, TISCO , LISCO | ||
| Material | 201 202 301 304 304L | ||
| Certificate | ISO9001,BV,SGS or as per customer. | ||
| Surface | 2B 2D BA(bright annealed) No.1 8K HL(Hair Line) PVC | ||
| Size | According to customer request | ||
| Standard | AISI, ASTM, GB,BS,EN,JIS,DIN | ||
| Application |
Kitchenware, home appliances, construction decoration, stairs, refrigerated container, burner parts, exhaust parts of auto |
||
| Feature | Representative type of Ferrite stainless steel, with magnetic | ||
| good cost performance, price stability | |||
|
Good shaping capability, weld bending capability, high thermal conductivity, low thermal expansion |
|||
| Advantages | Strong corrosion and decorative effect | ||
| TradeTerms | FOB, CFR, CIF, EXW. | ||
| Payment Terms |
T/T,L/C at sight 30%T/T in advance,balance 70% should be paid after receiving the copy of BL. |
||
|
Cooperation Ship-owner |
MSK, CMA, MSC, HMM, COSCO, | ||
Product Details
| Product name | 201/202/304 Stainless Steel Pipe/Tube |
| Standard | ASME, ASTM, EN ,BS,GB,DIN, JIS etc |
| Brand | 201/202/304/304L |
| Certificate | BV, ISO, CE, SGS etc |
| Type | Seamless & welded |
| Outter Diameter (OD) | 3-1220mm |
| Thickness | 0.5-50mm |
| Length | 6000mm 5800mm 12000mm or Customized |
| Technique | Cold Drawn or Hot |
| Surface | 2B, No.1, No.4, HL, BA, 8K etc |
| Application | Stainless steel sheet applies to construction field, ships building industry, petroleum & chemical industries,war and electricity industries, food processing and medical industry, boiler heat exchanger,machinery and hardware fields. |
| Packing | Standard export sea-worthy packing |
| Delivery Time | 7-15 Working Days after Deposit |
| TradeTerms | FOB, CFR, CIF, EXW |
| Payment Terms | 30%T/T,L/C |
Surface Description
| Surface | Definition | Application |
| No.1 | The surface finished by heat treatment and pickling or processes corresponding there to after hot rolling. | Chemical tank, pipe etc. |
| No.3 | Those finished by polishing with No.100 to No.120 abrasives specified in JIS R6001. | Kitchen utensils, Building construction etc. |
| No.4 | Those finished by polishing with No.150 to No.180 abrasives specified in JIS R6001. | Kitchen utensils, Building construction, Medical equipment etc. |
| 2B | Those finished, after cold rolling, by heat treatment, pickling or other equivalent treatment and lastly by cold rolling to given appropriate luster. | Medical equipment, Food industry, Construction material, Kitchen utensils etc. |
| BA (No.6) | Those processed with bright heat treatment after cold rolling. | Kitchen utensils, Electric equipment, Building construction etc. |
| Mirror (No.8) | Shinning like a mirror | Building construction, decoration etc. |
| Hairline | Those finished polishing so as to give continuous polishing streaks by using abrasive of suitable grain size. | Building Construction etc. |
Application
Chemical Composition
| Grade | C | Si | Mn | P | S | Ni | Cr | Mo |
| 201 | ≤0 .15 | ≤0 .75 | 5. 5-7. 5 | ≤0.06 | ≤ 0.03 | 3.5 -5.5 | 16 .0 -18.0 | - |
| 202 | ≤0 .15 | ≤l.0 | 7.5-10.0 | ≤0.06 | ≤ 0.03 | 4.0-6.0 | 17.0-19.0 | - |
| 301 | ≤0 .15 | ≤l.0 | ≤2.0 | ≤0.045 | ≤ 0.03 | 6.0-8.0 | 16.0-18.0 | - |
| 302 | ≤0 .15 | ≤1.0 | ≤2.0 | ≤0.035 | ≤ 0.03 | 8.0-10.0 | 17.0-19.0 | - |
| 304 | ≤0 .0.08 | ≤1.0 | ≤2.0 | ≤0.045 | ≤ 0.03 | 8.0-10.5 | 18.0-20.0 | - |
| 304L | ≤0.03 | ≤1.0 | ≤2.0 | ≤0.035 | ≤ 0.03 | 9.0-13.0 | 18.0-20.0 | - |
| 309S | ≤0.08 | ≤1.0 | ≤2.0 | ≤0.045 | ≤ 0.03 | 12.0-15.0 | 22.0-24.0 | - |
| 310S | ≤0.08 | ≤1.5 | ≤2.0 | ≤0.035 | ≤ 0.03 | 19.0-22.0 | 24.0-26.0 | |
| 316 | ≤0.08 | ≤1.0 | ≤2.0 | ≤0.045 | ≤ 0.03 | 10.0-14.0 | 16.0-18.0 | 2.0- |
| 316L | ≤0 .03 | ≤1.0 | ≤2.0 | ≤0.045 | ≤ 0.03 | 12.0 - 15.0 | 16 .0 -1 8.0 | 2.0 - |
| 321 | ≤ 0 .08 | ≤1.0 | ≤2.0 | ≤0.035 | ≤ 0.03 | 9.0 - 13 .0 | 17.0 -1 9.0 | - |
| 630 | ≤ 0 .07 | ≤1.0 | ≤1.0 | ≤0.035 | ≤ 0.03 | 3.0-5.0 | 15.5-17.5 | - |
| 631 | ≤0.09 | ≤1.0 | ≤1.0 | ≤0.030 | ≤0.035 | 6.50-7.75 | 16.0-18.0 | - |
| 904L | ≤ 2 .0 | ≤0.045 | ≤1.0 | ≤0.035 | - | 23.0·28.0 | 19.0-23.0 | 4.0-5.0 |
| 2205 | ≤0.03 | ≤1.0 | ≤2.0 | ≤0.030 | ≤0.02 | 4.5-6.5 | 22.0-23.0 | 3.0-3.5 |
| 2507 | ≤0.03 | ≤0.8 | ≤1.2 | ≤0.035 | ≤0.02 | 6.0-8.0 | 24.0-26.0 | 3.0-5.0 |
| 2520 | ≤0.08 | ≤1.5 | ≤2.0 | ≤0.045 | ≤ 0.03 | 0.19 -0. 22 | 0. 24 -0 . 26 | - |
| 410 | ≤0.15 | ≤1.0 | ≤1.0 | ≤0.035 | ≤ 0.03 | - | 11.5-13.5 | - |
| 430 | ≤0.1 2 | ≤0.75 | ≤1.0 | ≤ 0.040 | ≤ 0.03 | ≤0.60 | 16.0 -18.0 | - |
Packaging & Shipping
FAQ
Q1: ARE YOU FACTORY OR TRADER?
A1: Our company is a cold rolling manufacturer of magnetic stainless steel coil since 2009. We've gained our Export Right and become an integrated company of industry and trade in order to satisfy buyer's multi-request on different material and products.
Q2: WHICH MATERIAL/PRODUCTS YOU CAN PROVIDE?
A2: Stainless Steel Coils / Strips, Stainless Steel Sheets / Plates, Stainless Steel Circles / Discs, Decorative Stainless Steel Sheets.
Q3: HOW TO GET A SAMPLE?
A3: FREE samples are available for your checking and testing. And to get free samples, you need to send us you detailed receiving address (including post code) and your DHL/FedEx/UPS account for collecting samples, courier cost will be paid in your side.
Q4: HOW TO VISIT YOUR FACTORY?
A4: Most of the main cities have flights to Wuxi; you can take flight to Wuxi Shuofang International Airport.
If you come from Shanghai, it will take 2 hours by flight (every day 5 flights).
If you come from Hongkong, it will take 1 hour by flight (every day 1 flight around noon time).
